技术参数/击穿电压： | 36.7 V|36.7 V |
|
技术参数/电路数： | 1 |
|
技术参数/针脚数： | 2 |
|
技术参数/耗散功率： | 6.5 W |
|
技术参数/钳位电压： | 53.3 V |
|
技术参数/最大反向电压（Vrrm）： | 33V |
|
技术参数/测试电流： | 1 mA |
|
技术参数/最大反向击穿电压： | 40.6 V |
|
技术参数/脉冲峰值功率： | 1500 W |
|
技术参数/最小反向击穿电压： | 36.7 V |
|
技术参数/工作温度(Max)： | 150 ℃ |
|
技术参数/工作温度(Min)： | -55 ℃ |
|
技术参数/工作结温： | -55℃ ~ 150℃ |
|
封装参数/安装方式： | Surface Mount |
|
封装参数/引脚数： | 2 |
|
封装参数/封装： | DO-214AB |
|
外形尺寸/长度： | 7.11 mm |
|
外形尺寸/宽度： | 6.22 mm |
|
外形尺寸/高度： | 2.42 mm |
|
外形尺寸/封装： | DO-214AB |
|
物理参数/工作温度： | -55℃ ~ 150℃ |
|
其他/产品生命周期： | Active |
|
其他/包装方式： | Tape & Reel (TR) |
|
其他/最小包装： | 850 |
|
其他/制造应用： | 工业, 计算机和计算机周边, 照明, 车用, 消费电子产品, 电源管理, 通信与网络 |
|
符合标准/RoHS标准： |
| |
符合标准/含铅标准： | Lead Free |
|
海关信息/ECCN代码： | EAR99 |
|
| 型号 | 品牌 | 相似度 | 封装 | 简介 | 数据手册 | |
|---|---|---|---|---|---|---|
|
|
General Semiconductor | 功能相似 |
STMICROELECTRONICS SM15T33A TVS二极管, TVS, Transil SM15T系列, 单向, 28.2 V, 59 V, DO-214AB, 2 引脚
|
|||
|
|
Vishay Semiconductor (威世) | 功能相似 | DO-214AB |
STMICROELECTRONICS SM15T33A TVS二极管, TVS, Transil SM15T系列, 单向, 28.2 V, 59 V, DO-214AB, 2 引脚
|
||
SMCJ30A
|
YENJI (台湾元基) | 功能相似 | DO-214AB |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
|
|
Brightking (君耀电子) | 功能相似 | DO-214AB |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
SMCJ30A
|
JXND (嘉兴南电) | 功能相似 | SMC |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
|
|
Socay Electronics (硕凯) | 功能相似 | SMC |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
SMCJ30A
|
DC Components | 功能相似 |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
|||
|
|
Jingdao (晶导) | 功能相似 | SMC |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
|
|
Vishay Semiconductor (威世) | 功能相似 | SMC |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
|
|
LGE (鲁光) | 功能相似 | DO-214AB |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
SMCJ30A
|
SHIKUES (时科) | 功能相似 |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
|||
|
SMCJ30A
|
Zowie Technology (智威) | 功能相似 |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
|||
SMCJ30A
|
Fairchild (飞兆/仙童) | 功能相似 | DO-214AB-2 |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
SMCJ30A
|
Meritek | 功能相似 | - |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
|
SMCJ30A
|
AVX (艾维克斯) | 功能相似 | DO-214AB |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
SMCJ30A
|
Bourns J.W. Miller (伯恩斯) | 功能相似 | DO-214AB |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
SMCJ30A
|
Littelfuse (力特) | 功能相似 | DO-214AB-2 |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
|
|
Taiwan Semiconductor (台湾半导体) | 功能相似 | DO-214AB |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
SMCJ30A
|
Multicomp | 功能相似 | DO-214AB |
TVS Diodes SMT Unidirectional 1500W, SMCJ Series, Littelfuse ### 瞬态电压抑制器，Littelfuse
|
||
SMCJ33A
|
Multicomp | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
|
|
SMC | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
SMCJ33A
|
JXND (嘉兴南电) | 类似代替 | SMC |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
|
|
SMC Diode Solutions | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
SMCJ33A
|
Bourns J.W. Miller (伯恩斯) | 类似代替 | DO-214AB-2 |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
|
|
MDE Semiconductor | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
|
|
Brightking (君耀电子) | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
SMCJ33A
|
Fairchild (飞兆/仙童) | 类似代替 | DO-214AB-2 |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
SMCJ33A
|
Meritek | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
|
SMCJ33A
|
PANJIT Touch Screens | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
SMCJ33A
|
Good-Ark Electronics (固锝) | 类似代替 | SMC |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
SMCJ33A
|
Taiwan Semiconductor (台湾半导体) | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
SMCJ33A
|
YENJI (台湾元基) | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
|
|
AVX (艾维克斯) | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
SMCJ33A
|
ON Semiconductor (安森美) | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
|
|
Micro Commercial Components (美微科) | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
||
|
|
Vishay Semiconductor (威世) | 类似代替 | DO-214AB |
TVS 二极管 ON Semiconductor SMCJ33A 单向, 1500W, 53.3V, 2针 DO-214AB (SMC)封装
|
