技术参数/额定电压(DC): 56.0 V
技术参数/工作电压: 47.8 V
技术参数/电容: 330 pF
技术参数/额定功率: 1.50 kW
技术参数/击穿电压: 53.2 V|53.2 V
技术参数/耗散功率: 1.5 kW
技术参数/钳位电压: 77 V
技术参数/测试电流: 1 mA
技术参数/脉冲峰值功率: 1500 W
技术参数/最小反向击穿电压: 53.2 V
技术参数/工作温度(Max): 175 ℃
技术参数/工作温度(Min): -55 ℃
封装参数/安装方式: Through Hole
封装参数/引脚数: 2
封装参数/封装: DO-201
外形尺寸/长度: 9.5 mm
外形尺寸/直径: 5.30 mm
外形尺寸/封装: DO-201
物理参数/工作温度: -55℃ ~ 175℃ (TJ)
其他/产品生命周期: Active
其他/包装方式: Bulk
其他/制造应用: 通用
符合标准/RoHS标准: RoHS Compliant
符合标准/含铅标准: Lead Free
| 型号 | 品牌 | 相似度 | 封装 | 简介 | 数据手册 | |
|---|---|---|---|---|---|---|
1.5KE56CA
|
Multicomp | 类似代替 | DO-201 |
Trans Voltage Suppressor Diode, 1500W, 47.8V V(RWM), Bidirectional, 1Element, Silicon, DO-201, PLASTIC PACKAGE-2
|
||
1.5KE56CA
|
ST Microelectronics (意法半导体) | 类似代替 | DO-201 |
Trans Voltage Suppressor Diode, 1500W, 47.8V V(RWM), Bidirectional, 1Element, Silicon, DO-201, PLASTIC PACKAGE-2
|
||
|
|
Vishay Semiconductor (威世) | 类似代替 | DO-201 |
Trans Voltage Suppressor Diode, 1500W, 47.8V V(RWM), Bidirectional, 1Element, Silicon, DO-201, PLASTIC PACKAGE-2
|
||
1.5KE56CA
|
JXND (嘉兴南电) | 类似代替 | DO-201 |
Trans Voltage Suppressor Diode, 1500W, 47.8V V(RWM), Bidirectional, 1Element, Silicon, DO-201, PLASTIC PACKAGE-2
|
||
1.5KE56CA
|
Taiwan Semiconductor (台湾半导体) | 类似代替 | DO-201 |
Trans Voltage Suppressor Diode, 1500W, 47.8V V(RWM), Bidirectional, 1Element, Silicon, DO-201, PLASTIC PACKAGE-2
|
||
1.5KE56CA
|
ETC | 类似代替 |
Trans Voltage Suppressor Diode, 1500W, 47.8V V(RWM), Bidirectional, 1Element, Silicon, DO-201, PLASTIC PACKAGE-2
|
|||
|
1.5KE56CA
|
Micro Commercial Components (美微科) | 类似代替 | DO-201AE |
Trans Voltage Suppressor Diode, 1500W, 47.8V V(RWM), Bidirectional, 1Element, Silicon, DO-201, PLASTIC PACKAGE-2
|
||
|
1.5KE56CA
|
Fagor Electronica (法格) | 类似代替 | DO-201AE |
Trans Voltage Suppressor Diode, 1500W, 47.8V V(RWM), Bidirectional, 1Element, Silicon, DO-201, PLASTIC PACKAGE-2
|
||
|
1.5KE56CA
|
World Products | 类似代替 | DO-201 |
Trans Voltage Suppressor Diode, 1500W, 47.8V V(RWM), Bidirectional, 1Element, Silicon, DO-201, PLASTIC PACKAGE-2
|
||
|
1.5KE56CA
|
DB Lectro | 类似代替 |
Trans Voltage Suppressor Diode, 1500W, 47.8V V(RWM), Bidirectional, 1Element, Silicon, DO-201, PLASTIC PACKAGE-2
|
